Model Code
|
Frame
|
Input Current(A) 30Ph
|
Output Current(A) 30Ph
|
Typical Motor(kW)
|
|
NV-L-A/B-4002
|
C
|
6.5
|
5.1
|
2.2
|
|
NV-L-A/B-4003
|
C
|
10.5
|
9.0
|
3.7
|
|
NV-L-A/B-4005
|
C
|
14.8
|
13.0
|
5.5
|
|
NV-L-A/B-4007
|
D
|
20.5
|
18.0
|
7.5
|
|
NV-L-A/B-4011
|
D
|
29.0
|
27.0
|
11.0
|
|
NV-L-A/B-4015
|
D
|
36.0
|
33.0
|
15.0
|
|
NV-L-A/B-4018
|
E
|
41.0
|
39.0
|
18.5
|
|
NV-L-A/B-4022
|
E
|
49.5
|
48.0
|
22.0
|
|
NV-L-A/B-4030
|
E
|
62.0
|
60.0
|
30.0
|
|
NV-L-A/B-4037
|
F
|
77.0
|
75.0
|
37.0
|
|
NV-L-A/B-4045
|
F
|
93.0
|
91.0
|
45.0
|
|
Model Code
|
Height(H)
|
Width(W)
|
Depth(D)
|
Max resistor(Ω)
|
Min resistor(Ω)
|
Power of braking resistor(W)
|
Braking Unit
|
|
NV-L-A/B-4002
|
347.0mm
|
223.0mm
|
143.0mm
|
290.0
|
230.0
|
600
|
Built-In
|
|
NV-L-A/B-4003
|
347.0mm
|
223.0mm
|
143.0mm
|
170.0
|
135.0
|
1100
|
|
|
NV-L-A/B-4005
|
347.0mm
|
223.0mm
|
143.0mm
|
115.0
|
90.0
|
1600
|
|
|
NV-L-A/B-4007
|
347.0mm
|
223.0mm
|
173.5mm
|
85.0
|
65.0
|
2500
|
|
|
NV-L-A/B-4011
|
347.0mm
|
223.0mm
|
173.5mm
|
55.0
|
43.0
|
3500
|
|
|
NV-L-A/B-4015
|
347.0mm
|
223.0mm
|
173.5mm
|
43.0
|
35.0
|
4500
|
|
|
NV-L-A/B-4018
|
350.0mm
|
210.0mm
|
188.0mm
|
34.0
|
25.0
|
5500
|
|
|
NV-L-A/B-4022
|
350.0mm
|
210.0mm
|
188.0mm
|
24.0
|
22.0
|
6500
|
|
|
NV-L-A/B-4030
|
554.5mm
|
289.6mm
|
223.0mm
|
20.0
|
16.0
|
9000
|
|
|
NV-L-A/B-4037
|
549.0mm
|
385.0mm
|
265.0mm
|
16.0
|
13.0
|
11000
|
External
|
|
NV-L-A/B-4045
|
549.0mm
|
385.0mm
|
265.0mm
|
14.0
|
11.0
|
13500
|
|
Model Code
|
Frame
|
Input Current(A) 10Ph
|
Input Current(A) 30Ph
|
Output Current(A) 10Ph
|
Output Current(A) 30Ph
|
Typical Motor(kW)
|
|
NV-L-A/B-2002
|
C
|
9.2
|
11.0
|
5.2
|
9.6
|
1.1/2.2
|
|
NV-L-A/B-2003
|
C
|
13.3
|
17.0
|
7.5
|
14.0
|
1.5/3.7
|
|
220-NV-L-A/B-4007
|
D
|
17.9
|
20.5
|
10.3
|
18.0
|
2.2/4.0
|
|
220-NV-L-A/B-4011
|
D
|
25.3
|
29.0
|
15.5
|
27.0
|
3.7/5.5
|
|
220-NV-L-A/B-4015
|
D
|
31.3
|
36.0
|
19.0
|
33.0
|
4.0/7.5
|
|
220-NV-L-A/B-4018
|
E
|
34.6
|
41.0
|
22.5
|
39.0
|
5.5/111.0
|
|
220-NV-L-A/B-4022
|
E
|
42.6
|
49.0
|
27.7
|
48.0
|
11.0/15.0
|
|
220-NV-L-A/B-4030
|
E
|
52.6
|
62.0
|
34.6
|
60.0
|
15.0/18.5
|
|
Model Code
|
Height(H)
|
Width(W)
|
Depth(D)
|
Max resistor(Ω)
|
Min resistor(Ω)
|
Power of braking resistor(W)
|
Braking Unit
|
|
NV-L-A/B-2002
|
347.0mm
|
223.0mm
|
143.0mm
|
145.0/72.0
|
125.0/65.0
|
300/600
|
Built-In
|
|
NV-L-A/B-2003
|
347.0mm
|
223.0mm
|
143.0mm
|
105.0/54.0
|
90.0/50.0
|
450/1100
|
|
|
220-NV-L-A/B-4007
|
347.0mm
|
223.0mm
|
173.5mm
|
72.0/40.0
|
63.0/35.0
|
600/1200
|
|
|
220-NV-L-A/B-4011
|
347.0mm
|
223.0mm
|
173.5mm
|
43.0/29.0
|
37.0/25.0
|
1100/1600
|
|
|
220-NV-L-A/B-4015
|
347.0mm
|
223.0mm
|
173.5mm
|
40.0/26.0
|
35.0/22.0
|
1200/2500
|
|
|
220-NV-L-A/B-4018
|
350.0mm
|
210.0mm
|
188.0mm
|
29.0/14.5
|
25.0/13.0
|
1600/3500
|
|
|
220-NV-L-A/B-4022
|
350.0mm
|
210.0mm
|
188.0mm
|
18.0/13.0
|
16.0/12.5
|
3500/4500
|
|
|
220-NV-L-A/B-4030
|
554.5mm
|
289.6mm
|
223.0mm
|
13.0/12.5
|
13.0/12.0
|
4500/5500
|
|
Model Code
|
Rated Power(kVA)
|
Rated Output Current(A)
|
Suitable Motor Power(kW)
|
Model Code
|
Rated Power(kVA)
|
Rated Output Current(A)
|
Suitable Motor Power(kW)
|
|
200V Inverter
|
400V Inverter
|
||||||
|
2S01P1
|
2.3
|
6.0
|
1.1
|
4T01P1
|
2.7
|
3.5
|
1.1
|
|
2S02P2
|
4.6
|
12
|
2.2
|
4T02P2
|
4.7
|
6.2
|
2.2
|
|
2S03P7
|
6.9
|
18
|
3.7
|
4T03P7
|
6.9
|
9
|
3.7
|
|
2T05P5
|
9.5
|
25
|
5.5
|
4T05P5
|
8.5
|
13
|
5.5
|
|
2T07P5
|
12.8
|
33
|
7.5
|
4T07P5
|
14
|
18
|
7.5
|
|
2T0011
|
17.9
|
47
|
11
|
4T0011
|
18
|
27
|
11
|
|
2T0015
|
23
|
60
|
15
|
4T0015
|
24
|
34
|
15
|
|
2T18P5
|
29
|
75
|
18.5
|
4T18P5
|
29
|
41
|
18.5
|
|
2T0022
|
32
|
80
|
22
|
4T0022
|
34
|
48
|
22
|
