Home / Products / Elevator / Passenger Elevator / VTEP112 Elevadores High-Speed Passenger Elevator for Fast Vertical Movement
Passenger Elevator
Product Specifications
Load(kg) Speed (m/s) Control mode Internal car size  (mm) Door size (mm) Hoistway(mm) Generator room with one elevator (mm) Generator room with two elevator (mm)
C.W C.D C.H D.H H.W H.W H.D P.H HR.H MR.W MR.D MR.H MR.W MR.D MR.H
450 1 VVVF 1100 1000 2500 800 2100 1850 1700 1500 4500 2500 3300 2500 4500 3330 2500
1.75 1700 4800
630 1 1400 1100 2500 800 2100 2000 1800 1500 4500 2500 3300 2500 4500 3330 2500
1.75 1700 4800
800 1 1400 1350 2500 800 2100 2000 2000 1500 4500 2600 3650 2500 4600 3650 2500
1.75 1700 4800
2 1900 5100
2.5 2100 5300
1000 1 1600 1500 2500 900 2100 2200 2200 1500 4500 2800 3850 2500 5600 3850 2500
1.75 1700 4800
2 1900 5100
2.5 2100 5300
1150 1 1800 1500 2500 1100 2100 2400 2200 1500 4500 3200 3850 2500 6400 3750 2500
1.75 1700 4800
2 1900 5100
2.5 2100 5300
1350 1 1900 1600 2500 1100 2100 2500 2300 1500 4500 3250 3950 2500 6500 3950 2500
1.75 1700 4800
2 1900 5100
2.5 2100 5300
1600 1 2000 1750 2500 1100 2100 2600 2500 1500 4500 3250 4150 2500 6500 4150 2500
1.75 1700 4800
2 1900 5100
2.5 2100 5300
About Vitin Elevator

VITIN brand is committed to the research and development, manufacturing, and export of various elevator escalator products and elevator accessories. It has two business segments, VITIN Accessories Company and VITIN Elevator Technology Company.

At the same time, we also have a production capacity of 100000 tons of elevator guide rails per year under our own brand.

After years of development, companies under the VITIN brand have exported over 800 containers of elevator escalators and accessories annually, covering sales in more than 50 countries and regions including Europe, North and South America, Southeast Asia, and the Middle East.

Read More
  • 0

    Factory Area
  • 0+

    Employees
  • 0+

    Production Line
  • 0+

    Export Countries

Contact us now

VTEP112 Elevadores High-Speed Passenger Elevator for Fast Vertical Movement Industry knowledge
